Mini Oven Controller

OM21 Multi-functional Touching Oven Controller

Item No.: OM21-1
Humanized Intelligent Application      12 menus on line
Multi-Functional                                  LED display content
Delicious and Healthy                          AI Intelligent adjustable
Power saving mode
Description
Description

Our Multi-functional Touching Oven Controller Instruction

Humanized Intelligent Application:For Intelligent Application, you can adjust time, temperature quickly and make small adjustment. You can control oven panel, plan cooking, adjust and monitor cooking process, customize your own menu. It’s very easy to use it.
12 menus on line:Various menu application can offer you pre-set raw and delicious menu. If you don’t know how to make cooking, the menu will tell you what need to be prepared.  You can amend the menu according to your own requirement.




Our Multi-functional Touching Oven Controller Function

Muti-Functional:Supporting motor,furnace lamp,fan, which can be reduced as requested. It can be in fully compliance with the oven energy efficiency index,EMC standard.
LED display content:Function display (lower pipe, upper pipe, upper and lower pipe, rotation, fan, furnace lamp, ℃). User can choose different mode according to their needs and display correspondingly icons.
Glass panel:The panel uses toughened glass material. Easy clean, beautiful, high grade, good heat insulation, solid and durable.



Input Feature Input voltage range AC 85~265V
  Frequency 50HZ/60HZ
  Efficiency 80%
Output Feature Output voltage 12V/5V
  Output current MAX 800MA
  Output Voltage Accuracy
±5%
  Ripple 40m Vp-p
  Standby Power 1W
Protection Feature Overpower Protection 150-170% rated power, power will be restored after fault is removed
  Output short circuit protection DC output in short circuit, eliminating short circuit and power will recover
Environmental Parameter Working Temperature -20+85
Safe And EMC Standard Safe standard MEET- GB4943
  Withstand voltage CE  1500V/5Ma/3sec
  Insulation resistance I/P-O/P 500VDC/100MΩ hms
