EQ01 Self-design Laundry Machine Control Board

No.EQ01-2
This washing machine control board features an advanced LED display mode with a vibrant red screen, providing users with a clear and intuitive interface. The control panel is designed with 9 physical buttons for straightforward operation
  • EQ01 Self-design Laundry Machine Control Board
  • EQ01 Self-design Laundry Machine Control Board
Description
Product Overview:
This washing machine control board features an advanced LED display mode with a vibrant red screen, providing users with a clear and intuitive interface. The control panel is designed with 9 physical buttons for straightforward operation, allowing users to easily select and customize washing programs. It boasts a wide input voltage range from AC175-265V, ensuring compatibility in various regions globally, with a working voltage of standard 230VAC, supporting both 50Hz and 60Hz working frequencies for versatile application. The relay's standby power consumption is less than 0.5W, and less than 1W during operation, reflecting efficient energy use and environmental consciousness.
Product Features:
AIntelligent Control Mode: The 9 physical buttons offer a simple and understandable operation, enabling quick selection of various washing modes like standard wash, quick wash, anti-wrinkle wash, and silk washing.
Energy Efficiency: Optimized power design for low-energy consumption in both standby and active states, significantly reducing energy use.
Versatile Washing Programs: Includes standard wash, quick wash, anti-wrinkle wash, silk wash, and drying functions to meet the washing needs of different garments.
Enhanced User Experience: A user-friendly interface accompanied by pleasant sound prompts improves user interaction.
Child Lock Safety: Features a child lock control to ensure safety in households with young children.
Scheduled Washing: An advanced appointment feature allows users to set the washing time flexibly according to their schedule.
Washing Count View: Users can easily monitor the number of wash cycles, aiding in managing the washing routine of garments.
Customized Laundry Process: With a self-developed control board, users can customize the laundry process according to personal requirements, adding to the flexibility of use.
Overall, this washing machine control board is designed to meet the modern household's demands for intelligent and personalized laundry solutions, with its user-centric design, energy-saving attributes, and highly customizable functions.
